The Higrade 1200 × 800 × 130 mm presswood pallet is a two-way entry, single-deck moulded pallet weighing only 15 kg ± 1 kg — about one third lighter than an equivalent solid-wood pallet, which cuts manual handling strain and freight weight. Pressed from recycled wood, straw and bamboo at over 200 °C and more than 20 MPa with a patented modified MDI adhesive, it carries more than 2,000 kg dynamically and 6,000 kg statically, and its 93 mm fork opening suits standard powered and hand trucks. The high-temperature process makes the pallet pest-free and ISPM 15 exempt, so export shipments need no fumigation, heat treatment or IPPC marking. Water-immersion thickness swelling stays at 13 % and there is no formaldehyde release, making it suitable for chilled storage.
Specifications
| Size | 1200 × 800 × 130 mm |
|---|---|
| Series | Single-Deck Series |
| Fork entry | Two-way entry |
| Fork entry height | 93 mm |
| Dynamic load | > 2,000 kg |
| Static load | > 6,000 kg |
| Weight | 15 kg ± 1 kg |
| Material | Recycled wood / straw / bamboo + modified MDI adhesive (PCT/CN2022/138349) |
| Moisture content | ≤ 7 % |
| 24 h water-immersion thickness swelling | 13 % |
| Export quarantine | ISPM 15 exempt — no fumigation, no IPPC mark |
Why Choose the 1200 × 800 mm Wave-Pattern Pallet
This is the wave-pattern sibling of our diamond-pattern 1200 × 800 model: identical size, identical ratings, different deck geometry. The distinction matters more than it sounds. Wave ribs run across the deck in long parallel ridges, which produces a flatter, more continuous contact surface than a raised diamond lattice.
Where does that help? Three places. Sliding heavy cases into position during hand loading — ridges that run with the movement rather than against it. Flow-wrap and film-wrapped loads, which bridge a continuous surface better than a sharply raised grid. And cleaning: a wave deck sweeps out far more easily than a lattice with corners at every junction, which is why hygiene-sensitive operations tend to prefer it.
The specification is unchanged from the diamond version — 15 kg ± 1 kg, more than 2,000 kg dynamic, more than 6,000 kg static, 93 mm two-way fork entry, moulded above 200 °C at more than 20 MPa with a patented modified MDI adhesive, ≤ 7 % moisture, and 13 % thickness swelling after 24 hours immersion. It is also the reason this pallet works in chilled storage: the adhesive system releases no formaldehyde.
Where Wave-Pattern 1200 × 800 Pallets Are Used
- European retail and grocery supply — 1200 × 800 is the working standard for Euro-style trailers and store delivery.
- Weight-sensitive freight — at 15 kg ± 1 kg the pallet adds almost nothing to a chargeable shipment compared with sawn timber.
- Cold chain — stable through repeated condensation cycles, no formaldehyde release.
- Wash-down and hygiene-controlled areas — the continuous wave deck has no sharp internal corners to trap debris.
Shipping, Loading and Export Documentation
Two units side by side fill a standard trailer width, and cartons built on the Euro modular grid stack without overhang — that is why 1200 × 800 stays the default for European destinations. Pallets ship nested from Qingdao; tell us whether you are loading 20 GP, 40 GP or 40 HC and we will attach the exact count for this mould to the quotation. Every shipment leaves with our ISPM 15 exemption statement (processed above 200 °C — no fumigation, no heat treatment, no IPPC stamp required), certificate of origin including Form E / Form F / RCEP where eligible, commercial invoice, packing list and bill of lading.
Need a grippier surface instead? Ask about the diamond-pattern version of this mould — same size, same load ratings, raised lattice instead of parallel ridges.
Frequently Asked Questions
Do Higrade presswood pallets need ISPM 15 fumigation for export?
No. Higrade pallets are moulded at over 200 °C and more than 20 MPa, which eliminates insects and fungi in the raw material. They are treated as processed and pest-free under FAO IPPC ISPM 15, so no fumigation, heat treatment or IPPC marking is required.
What load can the 1200 × 800 × 130 mm presswood pallet carry?
More than 2,000 kg dynamic load and more than 6,000 kg static load, at a pallet weight of only 15 kg ± 1 kg — roughly one third lighter than an equivalent solid-wood pallet.
Is this pallet suitable for cold storage?
Yes. The modified MDI adhesive gives a 24-hour water-immersion thickness swelling of only 13 % and releases no formaldehyde, so the pallet works in chilled storage as well as dry warehouses.
